In the specification the key words “MUST”, “MUST NOT”, “REQUIRED”, “SHALL”, “SHALL NOT”, “SHOULD”, “SHOULD NOT”, “RECOMMENDED”, “MAY”, and “OPTIONAL” in this document are to be interpreted as described in RFC 2119.

Unless otherwise stated the API works case sensitive.

All names SHOULD be written in snake case, i.e. words are separated with one underscore character (_) and no spaces, with all letters lower-cased. Example: hello_world. This applies particularly to endpoints and JSON property names. HTTP header fields follow their respective casing conventions, e.g. Content-Type or OpenEO-Costs, despite being case-insensitive according to RFC 7230.

This uses HTTP REST Level 2 for communication between client and back-end server.

Public APIs MUST be available via HTTPS only.

Endpoints are made use meaningful HTTP verbs (e.g. GET, POST, PUT, PATCH, DELETE) whenever technically possible. If there is a need to transfer big chunks of data for a GET requests to the back-end, POST requests MAY be used as a replacement as they support to send data via request body. Unless otherwise stated, PATCH requests are only defined to work on direct (first-level) children of the full JSON object. Therefore, changing a property on a deeper level of the full JSON object always requires to send the whole JSON object defined by the first-level property.

Naming of endpoints follow the REST principles. Therefore, endpoints are centered around resources. Resource identifiers MUST be named with a noun in plural form except for single actions that can not be modelled with the regular HTTP verbs. Single actions MUST be single endpoints with a single HTTP verb (POST is RECOMMENDED) and no other endpoints beneath it.

The API uses JSON for request and response bodies whenever feasible. Services use JSON as the default encoding. Other encodings can be requested using Content Negotiation. Clients and servers MUST NOT rely on the order in which properties appears in JSON. Collections usually don't include nested JSON objects if those information can be requested from the individual resources.

The API is designed in a way that to most entities (e.g. collections and processes) a set of links can be added. These can be alternate representations, e.g. data discovery via OGC WCS or OGC CSW, references to a license, references to actual raw data for downloading, detailed information about pre-processing and more. Clients should allow users to follow the links.

Whenever links are utilized in the API, the description explains which relation (rel property) types are commonly used. A list of standardized link relations types is provided by IANA and the API tries to align whenever feasible.

Some very common relation types - usually not mentioned explicitly in the description of links fields - are:

1. self: which allows link to the location that the resource can be (permanently) found online.This is particularly useful when the data is data is made available offline, so that the downstream user knows where the data has come from.

2. alternate: An alternative representation of the resource, may it be another metadata standard the data is available in or simply a human-readable version in HTML or PDF.

3. about: A resource that is related or further explains the resource, e.g. a user guide.

The success of requests MUST be indicated using HTTP status codes according to RFC 7231.

If the API responds with a status code between 100 and 399 the back-end indicates that the request has been handled successfully.

In general an error is communicated with a status code between 400 and 599. Client errors are defined as a client passing invalid data to the service and the service correctly rejecting that data. Examples include invalid credentials, incorrect parameters, unknown versions, or similar. These are generally "4xx" HTTP error codes and are the result of a client passing incorrect or invalid data. Client errors do not contribute to overall API availability.

Server errors are defined as the server failing to correctly return in response to a valid client request. These are generally "5xx" HTTP error codes. Server errors do contribute to the overall API availability. Calls that fail due to rate limiting or quota failures MUST NOT count as server errors.

JSON error object

A JSON error object SHOULD be sent with all responses that have a status code between 400 and 599.

{
  "id": "936DA01F-9ABD-4D9D-80C7-02AF85C822A8",
  "code": "SampleError",
  "message": "A sample error message.",
  "url": "http://www.openeo.org/docs/errors/SampleError"
}

Sending code and message is REQUIRED.

• A back-end MAY add a free-form id (unique identifier) to the error response to be able to log and track errors with further non-disclosable details.

• The code is either one of the standardized textual openEO error codes or a proprietary error code.

• The message explains the reason the server is rejecting the request. For "4xx" error codes the message explains how the client needs to modify the request.

  By default the message MUST be sent in English language. Content Negotiation is used to localize the error messages: If an Accept-Language header is sent by the client and a translation is available, the message should be translated accordingly and the Content-Language header must be present in the response. See "How to localize your API" for more information.

• url is an OPTIONAL attribute and contains a link to a resource that is explaining the error and potential solutions in-depth.

Standardized status codes

The openEO API usually uses the following HTTP status codes for successful requests:

• 200 OK: Indicates a successful request with a response body being sent.
• 201 Created Indicates a successful request that successfully created a new resource. Sends a Location header to the newly created resource without a response body.
• 202 Accepted Indicates a successful request that successfully queued the creation of a new resource, but it has not been created yet. The response is sent without a response body.
• 204 No Content: Indicates a successful request without a response body being sent.

The openEO API has some commonly used HTTP status codes for failed requests:

• 400 Bad Request: The back-end responds with this error code whenever the error has its origin on client side and no other HTTP status code in the 400 range is suitable.

• 401 Unauthorized: The client did not provide any authentication details for a resource requiring authentication or the provided authentication details are not correct.

• 403 Forbidden: The client did provided correct authentication details, but the privileges/permissions of the provided credentials do not allow to request the resource.

• 404 Not Found: The resource specified by the path does not exist, i.e. one of the resources belonging to the specified identifiers are not available at the back-end. Note: Unsupported endpoints MUST use HTTP status code 501.

• 500 Internal Server Error: The error has its origin on server side and no other status code in the 500 range is suitable.

If a HTTP status code in the 400 range is returned, the client SHOULD NOT repeat the request without modifications. For HTTP status code in the 500 range, the client MAY repeat the same request later.

All HTTP status codes defined in RFC 7231 in the 400 and 500 ranges can be used as openEO error code in addition to the most used status codes mentioned here. Responding with openEO error codes 400 and 500 SHOULD be avoided in favor of any more specific standardized or proprietary openEO error code.

Date, time, intervals and durations are formatted based on ISO 8601 or its profile RFC 3339 whenever there is an appropriate encoding available in the standard. All temporal data are specified based on the Gregorian calendar.

The openEO API offers two forms of authentication by default:

• OpenID Connect (recommended) at GET /credentials/oidc
• Basic at GET /credentials/basic

After authentication with any of the methods listed above, the tokens obtained during the authentication workflows can be sent to protected endpoints in subsequent requests.

Further authentication methods MAY be added by back-ends.

Cross-origin resource sharing (CORS) is a mechanism that allows restricted resources [...] on a web page to be requested from another domain outside the domain from which the first resource was served. [...] CORS defines a way in which a browser and server can interact to determine whether or not it is safe to allow the cross-origin request. It allows for more freedom and functionality than purely same-origin requests, but is more secure than simply allowing all cross-origin requests.

Source: https://en.wikipedia.org/wiki/Cross-origin_resource_sharing

openEO-based back-ends are usually hosted on a different domain / host than the client that is requesting data from the back-end. Therefore most requests to the back-end are blocked by all modern browsers. This leads to the problem that the JavaScript library and any browser-based application can't access back-ends. Therefore, all back-end providers SHOULD support CORS to enable browser-based applications to access back-ends. CORS is a recommendation of the W3C organization. The following chapters will explain how back-end providers can implement CORS support.

All endpoints must respond to the OPTIONS HTTP method. This is a response for the preflight requests made by the browsers. It needs to respond with a status code of 204 and send the HTTP headers shown in the table below. No body needs to be provided.

Example request and response

Request:

OPTIONS /api/v1/jobs HTTP/1.1
Host: openeo.cloudprovider.com
Origin: http://client.org:8080
Access-Control-Request-Method: POST
Access-Control-Request-Headers: Authorization, Content-Type

Response:

HTTP/1.1 204 No Content
Access-Control-Allow-Origin: http://client.org:8080
Access-Control-Allow-Credentials: true
Access-Control-Allow-Methods: OPTIONS, GET, POST, PATCH, PUT, DELETE
Access-Control-Allow-Headers: Authorization, Content-Type
Content-Type: application/json

The following headers MUST be included with every response:

Tip: Most server can send the required headers and the responses to the OPTIONS requests globally. Otherwise you may want to use a proxy server to add the headers and OPTIONS responses.

A process is an operation that performs a specific task on a set of parameters and returns a result. An example is computing a statistical operation, such as mean or median, on selected EO data. A process is similar to a function or method in programming languages. In openEO, processes are used to build a chain of processes (process graph), which can be applied to EO data to derive your own findings from the data.

A pre-defined process is a process provided by the back-end. There is a set of predefined processes by openEO to improve interoperability between back-ends. Back-ends SHOULD follow these specifications whenever possible. Not all processes need to be implemented by all back-ends. See the process reference for pre-defined processes.

A user-defined process is a process defined by the user. It can directly be part of another process graph or be stored as custom process on a back-end. Internally it is a process graph with optional additional metadata.

A process graph chains specific process calls from the set of pre-defined and user-defined processes together. A process graph itself can be stored as a (user-defined) process again. Similarly to scripts in the context of programming, process graphs organize and automate the execution of one or more processes that could alternatively be executed individually. In a process graph, processes need to be specific, i.e. concrete values or "placeholders" for input parameters need to be specified. These values can be scalars, arrays, objects, references to parameters or previous computations or other process graphs.

Back-ends and users MAY define new proprietary processes for their domain.

Back-end providers MUST follow the schema for predefined processes as in GET /processes to define new processes. This includes:

• Choosing a intuitive and ideally unique name as process id, consisting of only letters (a-z), numbers and underscores.
• Defining the parameters and their exact (JSON) schemes.
• Specifying the return value of a process also with a (JSON) schema.
• Providing examples or compliance tests.
• Trying to make the process universally usable so that other back-end providers or openEO can adopt it.

Users MUST follow the schema for user-defined processes as in GET /process_graphs to define new processes. This includes:

• Choosing a intuitive and ideally unique name as process id, consisting of only letters (a-z), numbers and underscores.
• Defining the algorithm as a process graph.
• Optionally, specifying the additional metadata for processes.

If new process are potentially useful for other back-ends the openEO consortium is happily accepting pull requests to include them in the list of pre-defined processes.

Schemas

Each process parameter and the return values of a process define a schema that the value MUST comply to. The schemas are based on JSON Schema draft-07.

Two custom keywords have been defined:

• subtype for more fine-grained data-types than JSON Schema supports.
• parameters to specify parameters that processes can pass to other process graphs.

Subtypes

JSON Schema allows to specify only a small set of native data types (string, boolean, number, integer, array, object, null). To support more fine grained data types, a custom JSON Schema keyword has been defined: subtype. It works similarly as the JSON Schema keyword format and defines a number of subtypes for the native data types. These should be re-used in process schema definitions whenever suitable.

If a general data type such as string or number is used in a schema, all subtypes with the same parent data type can be passed, too. Clients should offer make passing subtypes as easy as passing a general data type. For example, a parameter accepting strings must also allow passing a string with subtype date and thus clients should encourage this by also providing a date-picker.

A list of predefined subtypes is available as JSON Schema.

As defined above, a process graph is a chain of processes with explicit values for their parameters. Technically, a process graph is defined to be a graph of connected processes with exactly one node returning the final result:

<ProcessGraph> := {
  "<ProcessNodeIdentifier>": <ProcessNode>,
  ...
}

<ProcessNodeIdentifier> is a unique key within the process graph that is used to reference (the return value of) this process in arguments of other processes. The identifier is unique only strictly within itself, excluding any parent and child process graphs. Process node identifiers are also strictly scoped and can not be referenced from child or parent process graphs. Circular references are not allowed.

Note: We provide a non-binding JSON Schema for basic process graph validation.

Processes (Process Nodes)

A single node in a process graph (i.e. a specific instance of a process) is defined as follows:

<ProcessNode> := {
  "process_id": <string>,
  "description": <string>,
  "arguments": <Arguments>,
  "result": true / false
}

A process node MUST always contain key-value-pairs named process_id and arguments. It MAY contain a description.

One of the nodes in a map of processes (the final one) MUST have the result flag set to true, all the other nodes can omit it as the default value is false. Having such a node is important as multiple end nodes are possible, but in most use cases it is important to exactly specify the return value to be used by other processes. Each child process graph must also specify a result node similar to the "main" process graph.

process_id MUST be any of the pre-defined or user-defined process IDs, which are all listed at GET /processes and GET /process_graphs. An example is load_collection to retrieve data from a specific collection for processing.

Arguments

A process can have an arbitrary number of arguments. Their name and value are specified in the process specification as an object of key-value pairs:

<Arguments> := {
  "<ParameterName>": <string|number|boolean|null|array|object|UserDefinedProcess|ParameterReference|ResultReference>
}

Notes:

• The specified data types are the native data types supported by JSON, except for UserDefinedProcess, ParameterReference and ResultReference.

• Objects are not allowed to have keys with the following names:

  • from_parameter, except for objects of type ParameterReference
  • from_node, except for objects of type ResultReference
  • process_graph, except for objects of type UserDefinedProcess

• Arrays and objects can also contain a UserDefinedProcess, a ParameterReference or a ResultReference. So back-ends must fully traverse the process graphs, including all children.

User-defined process

A user-defined process in a process graph is a simply a child process graph and thus to be evaluated as part of another process graph. It may consists only of an object with a key process_graph, but can be described with all additional properties available also for pre-defined processes such as an id, parameters, return values etc. In process graphs these additional properties are usually not used, except for validation purposes.

<UserDefinedProcess> := {
  "process_graph": <ProcessGraph>,
  ...
}

Accessing return values

A value of type <ResultReference> is an object with a key from_node with a <ProcessNodeIdentifier> as value:

<ResultReference> := {
  "from_node": "<ProcessNodeIdentifier>"
}

This tells the back-end that the process expects the result (i.e. the return value) from another node to be passed as argument. The <ProcessNodeIdentifier> is strictly scoped and can only referenced from within the same process graph, i.e. can not be referenced in child or parent process graphs.

Accessing process parameters

Example: You want to iterate over an array and calculate the absolute value of each value in the array. This can be achieved by executing the apply process in openEO and pass a process graph containing a single process absolute.

The parameters made available by the "parent" process (apply in this example) to the "child" process graph are the process graph parameters. Processes can access parameters by passing a certain type of object as argument to a processes. It is an object with key from_parameter specifying the name of the process graph parameter:

<ParameterReference> := {
  "from_parameter": "<ParameterReferenceName>"
}

The parameter names made available for <ParameterReferenceName> are defined and passed to the process graph by one of the parent entities. The parent could be a process such as apply or something else that executes a process graph, for example a secondary web service.

It is important to know that <ParameterReferenceName> is less strictly scoped than <ProcessNodeIdentifier>. <ParameterReferenceName> can be any parameter from the process graph or any of its parents. If there are multiple parameters with the same name, the parameter is resolved by starting in the current scope and then checking each parent for a suitable parameter until the "root" process graph is reached.

If the parent is a process, the parameter are defined in the parameters property of the corresponding JSON Schema. In case of the example given above, the parameter process in the process apply defines a process graph parameter named x and the process absolute expects an argument with the same name. The process graph for the example would look as follows:

{
  "process_id": "apply",
  "arguments": {
    "data": {"from_node": "loadcollection1"}
    "process": {
      "process_graph": {
        "abs1": {
          "process_id": "absolute",
          "arguments": {
            "x": {"from_parameter": "x"}
          },
          "result": true
        }
      }
    }
  }
}

loadcollection1 would be a result from another process, which is not part of this example.

Full example for an EVI computation

Deriving minimum EVI (Enhanced Vegetation Index) measurements over pixel time series of Sentinel 2 imagery. The main process graph in blue, child process graphs in yellow:

The process graph for the algorithm: pg-evi-example.json

Processes can run in three different ways:

1. Results can be pre-computed by creating a batch job. They are submitted to the back-end's processing system, but will remain inactive until explicitly put into the processing queue. They will run only once and store results after execution. Results can be downloaded. Batch jobs are typically time consuming and user interaction is not possible although log files are generated for them. This is the only mode that allows to get an estimate about time, volume and costs beforehand.

2. A more dynamic way of processing and accessing data is to create a secondary web service. They allow web-based access using different protocols such as OGC WMS (Open Geospatial Consortium Web Map Service), OGC WCS (Web Coverage Service) or XYZ tiles. These protocols usually allow users to change the viewing extent or level of detail (zoom level). Therefore, computations often run on demand so that the requested data is calculated during the request. Back-ends should make sure to cache processed data to avoid additional/high costs and reduce waiting times for the user.

3. Processes can also be executed on-demand (i.e. synchronously). Results are delivered with the request itself and no job is created. Only lightweight computations, for example previews, should be executed using this approach as timeouts are to be expected for long-polling HTTP requests.

Validation

Process graph validation is a quite complex task. There's a JSON schema for basic process graph validation. It checks the general structure of a process graph, but only checking against the schema is not fully validating a process graph. Note that this JSON Schema is probably good enough for a first version, but should be revised and improved for production. There are further steps to do:

1. Validate whether there's exactly one result: true per process graph.
2. Check whether the process names that are referenced in the field process_id are actually available. There's a custom format process-id, which can be used to check the value directly during validation against the JSON Schema.
3. Validate all arguments for each process against the JSON schemas that are specified in the corresponding process specifications.
4. Check whether the values specified for from_node have a corresponding node in the same process graph.
5. Validate whether the return value and the arguments requesting a return value with from_node are compatible.
6. Check the content of arrays and objects. These could include parameter and result references (from_node, from_parameter etc.).

Execution

To process the process graph on the back-end you need to go through all nodes/processes in the list and set for each node to which node it passes data and from which it expects data. In another iteration the back-end can find all start nodes for processing by checking for zero dependencies.

You can now start and execute the start nodes (in parallel, if possible). Results can be passed to the nodes that were identified beforehand. For each node that depends on multiple inputs you need to check whether all dependencies have already finished and only execute once the last dependency is ready.

Please be aware that the result node (result set to true) is not necessarily the last node that is executed. The author of the process graph may choose to set a non-end node to the result node!

General information about the API implementation and other supported capabilities at the back-end.

The following endpoints handle user profiles, accounting and authentication. See also Authentication. In general, the openEO API only defines a minimum subset of user management and accounting functionality. It allows to

• authenticate and authorize a user, which may include user registration with OpenID Connect,
• handle storage space limits (disk quota),
• manage billing, which includes to
  • query the credit a user has available,
  • estimate costs for certain operations (data processing and downloading),
  • get information about produced costs,
  • limit costs of certain operations.

Therefore, the API leaves some aspects open that have to be handled by the back-ends separately, including

• credential recovery, e.g. retrieving a forgotten password
• user data management, e.g. changing the users payment details or email address
• payments, i.e. topping up credits for pre-paid services or paying for post-paid services
• other accounting related tasks, e.g. creating invoices,
• user registration (except for user registration with OpenID Connect).

These endpoints allow to list the collections that are available at the back-end and can be used as data cubes for data processing.

For data discovery of Earth Observation Collections at the back-ends, openEO strives for compatibility with the specifications SpatioTemporal Asset Catalog (STAC) and OGC API - Features - Part 1: Core as far as possible. Implementing the data discovery endpoints of openEO should also produce valid STAC 0.9.0 and OGC API - Features 1.0 responses, including (partial) compatibility with their APIs.

The data discovery endpoints GET /collections and GET /collections/{name} are compatible with OGC API - Features and STAC. Both specifications define additional endpoints that need to be implemented to be fully compatible. The additional endpoints can easily be integrated into an openEO API implementation. A rough list of actions for compatibility is available below, but please refer to their specifications to find out the full details.

Content Extensions

STAC has several extensions that can be used to better describe your data. Clients and server are not required to implement all of them, so be aware that some clients may not be able to read all your metadata.

Some commonly used extensions that are relevant for datasets exposed through the openEO API are:

• Data Cube extension (part of the openEO API)
• EO (Electro-Optical) extension
• SAR extension
• Satellite extension
• Scientific extension

Provide data for download

If you'd like to provide your data for download in addition to offering the cloud processing service, you can implement the full STAC API. Therefore you can implement the endpoints GET /collections/{collectionId}/items and GET /collections/{collection-name}/items/{featureId} to support retrieval of individual items. To benefit from the STAC ecosystem and allow searching for items you can also implement POST /search and GET /search. Further information can be found in the STAC API repository and in the corresponding OpenAPI specification.

These endpoints allow to list the predefined processes that are available at the back-end. To list user-defined processes see 'User-Defined Processes'.

These endpoints allow to store and manage user-defined processes with their process graphs at the back-end.
